Sitting & Hanging Dual-use Stringing Block
Features:
- used for spreading wires in overhead transmission lines
- can be used either hanging type stringing block or skyward stringing block
- sheave can be nylon or aluminum
- support single sheave, double sheave and triple sheave
- sheave have different size
Product Category
Related products
- info@hwatian.com
- 0086 173 5252 6390
- Room 402, Unit 2, Building 6, No. 660, Huimin Community, Xiaodian Town, Hongqi District, Xinxiang City, Henan Province
Specification
| Model | Sheave Size (mm) | Wire Range (mm²) | Weight (KG) | Rated Capacity (T) |
| 80*35 | φ80*35 | 25-120 | 1.00 | 0.5 |
| 80*50 | φ80*50 | 25-180 | 1.00 | 0.5 |
| 100*35 | φ100*35 | 25-150 | 1.25 | 0.5 |
| 100*50 | φ100*50 | 25-180 | 1.25 | 0.5 |
| 120*60 | φ120*60 | 25-240 | 2.75 | 1.0 |
| 120*80 | φ120*80 | 25-300 | 3.00 | 1.0 |
| 150*60 | φ150*60 | 25-240 | 3.50 | 1.0 |
| 150*80 | φ150*80 | 25-300 | 4.00 | 2.0 |
| 200*60 | φ200*60 | 25-240 | 4.50 | 2.0 |
| 250*60 | φ250*60 | 25-240 | 6.00 | 2.0 |
| 320*80 | φ320*80 | 25-300 | 8.00 | 3.2 |
suppotr double and triple sheaves also
Surface can be silver galvanized or color galvanized
