Cable Pulling Winch
Key Features:
- Load Capacity:
- 3T Model: Handles loads up to 30kN, perfect for medium-duty applications.
- 5T Model: Capable of pulling loads up to 50kN, suitable for heavy-duty tasks.
- Multiple Power Options: Choose from gasoline, diesel, or electric motor to suit your operational needs.
- High Traction Speed: Designed for efficient cable pulling, with fast traction speeds to enhance productivity.
- Durable Construction: Built with high-quality materials to ensure reliability and longevity in harsh working conditions.
- User-Friendly Controls: Intuitive control system for easy operation, enhancing safety and efficiency.
Applications:
- Electrical cable installation
- Utility line construction
- Heavy lifting and pulling operations
Product Category
Related products
- info@hwatian.com
- 0086 173 5252 6390
- Room 402, Unit 2, Building 6, No. 660, Huimin Community, Xiaodian Town, Hongqi District, Xinxiang City, Henan Province
Performance and Characteristics
Mainly used for power transmission and transformation project(including underground power cable engineering), telecommunications, telecommunications engineering construction tower erection, traction cable, tighten the wire, lifting weights and toolds, especially suitable for small batch operations within the city.
Our Cable Pulling Winch is designed for efficient and reliable cable installation and pulling tasks. Available in two models—3T and 5T—this winch supports various power sources, including gasoline, diesel, and electric motors, making it a versatile tool for construction and utility projects.
| Model | Rotation direction | Gear | Rated Capacity | Traction Speed | Original Power | Weight |
| JJC-3S | Forward | Fast | 30kN | 4m/min | Diesel Engine 4kW | 100kg |
| Slow | 18kN | 6.6m/min | ||||
| Reversal | Slow | no lifting | 3.3m/min | |||
| JJQ-3S | Forward | Fast | 30kN | 4m/min | Gasoline Engine 4kW | 100kg |
| Slow | 18kN | 6.6m/min | ||||
| Reversal | Slow | no lifting | 3.3m/min | |||
| JJD-3S | Forward | Fast | 30kN | 4m/min | Electric Motor 4KW | 100kg |
| Slow | 18kN | 6.6m/min | ||||
| Reversal | Slow | no lifting | 3.3m/min | |||
| JJC-5S | Forward | Fast | 50kN | 4m/min | Diesel Engine 6.6kW | 150kg |
| Slow | 2.2kN | 9m/min | ||||
| Reversal | Slow | no lifting | 4m/min | |||
| JJQ-5S | Forward | Fast | 50kN | 4m/min | Gasoline Engine 6.6kW | 150kg |
| Slow | 2.2kN | 9m/min | ||||
| Reversal | Slow | no lifting | 4m/min | |||
| JJD-5S | Forward | Fast | 50kN | 4m/min | Electric Motor 6.6kW | 150kg |
| Slow | 2.2kN | 9m/min | ||||
| Reversal | Slow | no lifting | 4m/min |
